Specifications
| Table Size: | 24.8” x 24.8” (630 x 630mm) |
| Travel (X, Y, Z): |
43.3” x 36.2” x 41.3” (1,100 x 920 x 1,050mm) |
| Spindle Taper: | NST No. 50 |
| Spindle Speed: | 35~12,000rpm (8,000rpm Opt.) – Gear Drive, 4-Step |
| Tool Storage Capacity: | 62 Pcs. (122, 162, 212 Opt.) |
|
Tool Change Time (T-T/C-C): |
2.1 sec. /5.2 sec. |
|
Rapid Feed (X,Y,Z) Rapid Feed (B) |
2,362ipm (60m/min) 12,000deg./min. (33.3rpm) |
| Power Requirement: | 65KVA |
Features
• 12,000rpm and optional 8,000rpm geared spindle configurations. High speed, high torque. HSK-A100 spindle available as an option
• Positioning Accuracy: ±0.000079”/Full Stroke, Repeatability: ±0.000039”
• Solid box way construction, linear scales on all axes and twin ballscrew design in the X, Y and Z axes
• Full 4th axis rotary table for 360ᴼ cutting capability
• World's fastest rapid feed rates of 2,362ipm on induction hardened solid box ways
• Standard 2-station APC offers the ability to add pallets and pallet pool systems in the field
• Beats the competition in work envelope size and stroke!
• The ability to add 800mm tables in the field as an option
